Name: Bright 420 MPA 50mm Soft CuNi44 Heating Nickel Copper Rod
SKU: 0

sales@alloysfactory.com

+8618052778977

Bright 420 MPA 50mm Soft CuNi44 Heating Nickel Copper Rod

PRODUCT

MESSAGE

If you have any questions, please contact us and we will contact you as soon as possible.

Bright 420 MPA 50mm Soft CuNi44 Heating Nickel Copper Rod

Phone：+8618052778977

Email：sales@alloysfactory.com

WhatsApp：+8618052778977

Add：Building 10, Fuqian Xingzuo , Development Zone, Danyang City, Jiangsu Province

Inquire Now

◉ PRODUCT SPECIFICATION

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Nickel Copper

Nickel(Min):

44%

Resistivity:

0.5

Tensile Strength:

420 MPA

Density:

8.9 G/cm3

Application:

Heating, Resistivity

Condition:

Hard / Soft

Sureface:

Bright

Delivery Time:

7-20 Days

Maximum Temperature:

420℃

Melting Point:

1100℃

Name:

Resistance Heating Rod

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

420 MPA Nickel Copper Rod,50mm Soft Cupro Nickel Alloy,CuNi44 Nickel Copper Rod

Product Description

CuNi Series

Copper nickel alloy has low electric resisitance, good heat-resistant and corrosion-resistant, easy to be processed and lead welded. It is used to make the key components in the thermal overload relay, low resistance thermal circuit breaker, and the electrical appliances. It is also an important material for electrical heating cable.

Common Name:Constantan Rod

Copper Nickel alloy performance tables

Properties/ Material	Resistivity	Max.working temperature	Tensile strength	Melting point	Density	TCR	EMF vs Cu
	( 200C μΩ.m)	( 0C )	( Mpa )	( 0C )	( g/cm3 )	x10-6 / 0C	(μV/ 0C)
						(20~600 0C)	(0~100 0C)
NC003	0.03	200	210	1085	8.9	<100	-8
(CuNi1)
NC005	0.05	200	220	1090	8.9	<120	-12
(CuNi2)
NC010	0.1	220	250	1095	8.9	<60	-18
(CuNi6)
NC012	0.12	250	270	1097	8.9	<57	-22
(CuNi8)
NC015	0.15	250	290	1100	8.9	<50	-25
(CuNi10)
NC020	0.2	300	310	1115	8.9	<30	-28
(CuNi14)
NC025	0.25	300	340	1135	8.9	<25	-32
(CuNi19)
NC030	0.3	300	350	1150	8.9	<16	-34
(CuNi23)
NC035	0.35	350	400	1170	8.9	<10	-37
(CuNi30)
NC040	0.4	350	400	1180	8.9	0	-39
(CuNi34)
NC050	0.5	400	420	1200	8.9	<-6	-43
(CuNi44)
