Name: 0.5mmx180mm Soft MPA CuNi34 Nickel Copper Alloy 400
SKU: 0

sales@alloysfactory.com

+8618052778977

0.5mmx180mm Soft MPA CuNi34 Nickel Copper Alloy 400

PRODUCT

MESSAGE

If you have any questions, please contact us and we will contact you as soon as possible.

0.5mmx180mm Soft MPA CuNi34 Nickel Copper Alloy 400

Phone：+8618052778977

Email：sales@alloysfactory.com

WhatsApp：+8618052778977

Add：Building 10, Fuqian Xingzuo , Development Zone, Danyang City, Jiangsu Province

Inquire Now

◉ PRODUCT SPECIFICATION

Detail Information

Place of Origin:

China Jiangsu

Certification:

CE,ROHS

Material:

Nickel Copper

Nickel(Min):

34%

Resistivity:

0.4

Tensile Strength:

400MPA

Density:

8.9 G/cm3

Application:

Heating, Resistivity

Condition:

Hard / Soft

Sureface:

Bright

Delivery Time:

7-20 Days

Maximum Temperature:

350℃

Melting Point:

1180℃

Name:

Resistance Heating Strip

Packaging Details:

Spool package with Carton box, Coil package with polybag

Supply Ability:

500 tons per month

Highlight:

180mm Nickel Copper Alloy 400,Soft 400 MPA Copper Alloy,CuNi34 Strip Nickel Copper Alloy 400

Product Description

CuNi Series

Copper nickel CuNi34 alloy has low electric resisitance, which have 34% nickel and balance is copper, it is good heat-resistant and corrosion-resistant, easy to be processed and lead welded. It is used to make the key components in the thermal overload relay, low resistance thermal circuit breaker, and the electrical appliances. It is also an important material for electrical heating cable.

CuNi34 Copper Nickel alloy resistance heating strip.

Copper Nickel alloy performance tables

Properties/ Material	Resistivity	Max.working temperature	Tensile strength	Melting point	Density	TCR	EMF vs Cu
	( 200C μΩ.m)	( 0C )	( Mpa )	( 0C )	( g/cm3 )	x10-6 / 0C	(μV/ 0C)
						(20~600 0C)	(0~100 0C)
NC003	0.03	200	210	1085	8.9	<100	-8
(CuNi1)
NC005	0.05	200	220	1090	8.9	<120	-12
(CuNi2)
NC010	0.1	220	250	1095	8.9	<60	-18
(CuNi6)
NC012	0.12	250	270	1097	8.9	<57	-22
(CuNi8)
NC015	0.15	250	290	1100	8.9	<50	-25
(CuNi10)
NC020	0.2	300	310	1115	8.9	<30	-28
(CuNi14)
NC025	0.25	300	340	1135	8.9	<25	-32
(CuNi19)
NC030	0.3	300	350	1150	8.9	<16	-34
(CuNi23)
NC035	0.35	350	400	1170	8.9	<10	-37
(CuNi30)
NC040	0.4	350	400	1180	8.9	0	-39
(CuNi34)
NC050	0.5	400	420	1200	8.9	<-6	-43
(CuNi44)

The Form we could offer

Size Range		Image
Wire	dia 0.03-7.5mm
	dia 8.0-12.0mm
Ribbon	(0.05-0.35)*(0.5-6.0)mm

Strip	(0.50-2.5)*(5-180)mm

Rod	8-50mm

Product Description

CuNi Series

CuNi34 Copper Nickel alloy resistance heating strip.

Copper Nickel alloy performance tables

Properties/ Material	Resistivity	Max.working temperature	Tensile strength	Melting point	Density	TCR	EMF vs Cu
	( 200C μΩ.m)	( 0C )	( Mpa )	( 0C )	( g/cm3 )	x10-6 / 0C	(μV/ 0C)
						(20~600 0C)	(0~100 0C)
NC003	0.03	200	210	1085	8.9	<100	-8
(CuNi1)
NC005	0.05	200	220	1090	8.9	<120	-12
(CuNi2)
NC010	0.1	220	250	1095	8.9	<60	-18
(CuNi6)
NC012	0.12	250	270	1097	8.9	<57	-22
(CuNi8)
NC015	0.15	250	290	1100	8.9	<50	-25
(CuNi10)
NC020	0.2	300	310	1115	8.9	<30	-28
(CuNi14)
NC025	0.25	300	340	1135	8.9	<25	-32
(CuNi19)
NC030	0.3	300	350	1150	8.9	<16	-34
(CuNi23)
NC035	0.35	350	400	1170	8.9	<10	-37
(CuNi30)
NC040	0.4	350	400	1180	8.9	0	-39
(CuNi34)
NC050	0.5	400	420	1200	8.9	<-6	-43
(CuNi44)
